Finally starting to get some where now iv got all the parts to complete the build. After 4 hours of trying to sort out my cables this is how it looks. Iv also made a mounting plate for my top radiator to help make it fit better and also tried to make look like is floating

Another update for this week, received a new delivery of parts, which is everything I need now, thanks Scan Computers and Thermaltake UK : Almost done on the painting side of things: Also took a chunk off the motherboard tray and gave it a coat of paint: And cut two plexiglas panels for the top and bottom to be modded (the top needs some more paint...):

Gooood Moooorning Modding faaaaaaans! So with the motherboard heatsinks nicely brightened I couldn't just stick that black plastic shroud back over them. Luckily I have some 2mm aluminium laying about that I've had forever and this will make an ideal replacement. I started by tracing round the the original cover, but because it has mounting struts and other stuff underneath, this was better done turned upside down to get it flush(er) against the paper, which is why the drawing is backwards. Then I took measurements for the rest of the board so that I could expand it out a bit and cover up more of the motherboard. This is the area I want to cover, colour coding showing the original and then different additional bit that I might want to add. I did the drawing on card so that it would stay relatively flat once cut out and got it lined up with the mounting point and punched them through. Once on the board it didn't look right having a lot of square corners given the boards original angular designs, so I marked out bits I'd want tweaking with rough angles from the heatsinks. Back off the board I used the cover to get the proper angles and see about different levels of cropping. Couple of snips later and I think we have a winner! Now this was a fairly rough drawing so I then traced round this template in pencil and took to the drawing board to get all the lines true. Again I used the original to get the angled lines in, it was an awkward angle and I don't have anything like a sliding bevel. I could still find ones that were out like the one I circled in orange. With a couple of lines done this way I then turned the paper so the the angle was horizontal, checked them against each other to make sure they were correct and then filled in the rest. With the design completed I did a couple of photocopies and also scanned it for safe keeping. From right to left we have the original plan, the final design, the photocopy to be used as a template and the aluminium, with the original cover centre and glue to stick the template on. Only that's completely the wrong glue 😖 Looks more like spider spooge. 🤣 Still, it stuck that template down pretty good, if a little on the lumpy side. I also had to rub dirt around the edges where there was no paper to remove the tackiness of the glue and stop the jigsaw from sticking. That very morning I had been reading up on a cool little scratch build someone was doing as their first mod and advising themon how to cut outside the line and file in, so what do I do on the very first cut? Cut BANG ON the line 🤬🙄 It was the edge on the far right next to the SATA ports so wasn't a complete catastrophe, but was very careful and took my time with the rest and came out fine, although the small vertical edge under the angular protrusion top right was hard to get at. The Filing went ok, I'd bought a set of steel jaws for the workbench to clamp it in which helped keep it nice and steady. This tight angle was tough though as I didn't have a triangular file that matched or was under that radius. i had to edge in with the half round file, flipping it over every few strokes. A bit of folded sand paper helped get it a bit tighter, but it put up a good fight, Took a good lot of doing, had to go at it in a few goes to save me from injury. But was all this mess worth it? It fits! 🤘 There were a couple of areas that needed work that I highlighted in green, either to straighten them up, change the angle or stop it overhanging headers I'll need access to. Bang on. 👌 To get it to sit flush in the recesses of the M.2 heatsinks I needed to drill holes for the screws holding the heatsinks down. To mark where they were I put masking tape on the back, coloured the screw heads with whiteboard marker and pushed the piece onto them, being careful that it lined up with where it needed to sit. Seemed to work well. I used a punch to mark the centre and make sure the drill bit didn't wander. I thought the screw heads were 4mm so I drill a hole with a 4.2mm bit to give a little wiggle room, but I must have measure the wrong screws (the ones that will mount this to the motherboard i think) as they were a little too small. I needed 5.37mm holes minimum. My step bit had a 7/32" step which is 5.56mm and would do the job nicely. Unfortunately, due to either a wandering bit or inaccuracies in how I got the positioning the top hole was just out. 😞 To be honest I wasn't THAT upset. There were a few edges that were a bit naff and there were a couple of tweaks I wanted to make, so I widened those holes a fair bit so I could get it into place, check the fitment elsewhere and make sure the markings for the mounting holes were accurate, which they were. And just for fun I took off the paper and gave it a really quick and dirty "brushing" with a washing up scotch pad, but was mostly just from trying to get all that nasty glue off. Still looks pretty tasty 😍 It's a shame it's going to end up in the recycling, but for a first whack it's not gone too badly. I had prepared myself that it might take a couple of goes to get it right and with the design tweaks for Mk II already in my head, I wouldn't have been happy till I'd redone it anyway. So stay tuned crap fans! Plenty more of Makin's metal manipulation to come. Same Crap time, same Crap channel.

I cut the middle out of the back panel welded a frame then added some more sprockets and brake discs and painted it all white then added the screen

Not much to report this week I'm afraid, still awaiting delivery of the remaining components from Thermaltake. It has worked out well however, as I was able to finish up all of my academic work without any distraction; just sitting my last exam yesterday. So now I am done with everything and just waiting for my results! As soon as the rest of the parts arrive, I will finally be able to really get stuck in; so this past weekend I decided to do a few preliminary things to get the ball rolling. Since the weather was nice I decided to take a stab at cutting my first piece of acrylic: This particular sheet is actually gloss white, but comes with a protective blue film on both sides. The film is quite handy for plotting your guidelines, as well as providing some surface tension to prevent cracks or splintering. I just used a cheap jigsaw (nothing fancy) but with a high-quality metal-cutting blade. As long as you keep the speed slow and with no articulation, cutting acrylic this way is fairly straightforward. Just remember not to go too fast, otherwise it will melt back together. The radiator/fan brackets also needed a little bit of cutting with a dremel: Just little slots to allow the acrylic sheet to be flush with the frame. An alternative option would have been to put notches in the acrylic, but doing it that way would require pinpoint precision; whereas this way I could basially 'eyeball' it. Not bad for a first test-fit. I will need to trim the top bracket a little bit more, as the acrylic isn't perfectly perpindicular at that top-left corner. Plenty of other little bits of cutting to do as well, for cable and tubing access; as well as more acrylic pieces to measure and cut for the rest of the inside. Unfortunately I can't do that until the rest of the cooling parts come, as I need the exact measurements. It is nice and bare back here for now, but once all of the power/argb/fan cables are in, it is going to be a nightmare to tidy up. Well that's it for now, weather permitting I will do a little more acrylic work over the weekend. Now that all my academic work is out of the way I plan on making steady progress relatively quickly. The sooner I get everything assembled and mocked up, it will be much easier for my step-daughter to plan out the 'artsy' stuff. She has plenty of ideas, but it can be difficult to visualise without having the blank canvas set up to see how everything will look/fit. In the meantime, take care folks.

Just another quick update, started painting the outer panels, the copper colour is a base coat before adding a coat of gold and then red on top, could still do with a couple more coats of red: Added a bit of grime to the smaller parts of the case which have all been painted (they looked a bit too pristine on reflection): Added DC and Ethernet ports to the HDD access door: Cut the hole for the screen at the back (still needs tidying up and the frame painting): Will get some time at the weekend when I'm hoping to: Finish up on adding grime / wear to the smaller parts of the case Tidy up the LCD screen's mounting Get some primer on the frame Finish all airbrushing on panels / smooth down surfaces for gloss lacquer on top

VOTE FOR YOUR FAVORITE RIG! Round 2 has started! vote for your favorite rigs on the poll! Voting Ends: 5/20/2020 Timmy Parker - View 51 Marc Chibani - Core P5 Franco Warboy Martinelli - Core P5 George Antonopoulos - Core P5 AML Custom PC - A500 Rob "Deblow" Deluce - Level 20 GT tantric - Level 20 VT Douglas Alves Modding - Core V71 Turritopsis - Level 20 MT RYUTECH MODZ - Core P5 Илья Байда - Core P5 cristianomod - Level 20 GT primerajuly - Level 20 GT Explore Modding - Core P5 orkusmodding - Level 20 GT TantrumL - Core P5 TheTechAllen - Level 20 GT XneaLx ModPc Gaming - Level 20 VT Patrick Kahiga - View 71 Rich Stanton - Core P3

Thanks mate. After mulling it over though, I’m just not happy with it. It has become way too ‘busy’ due to that thick rad. I think I’m just going to bite the bullet and put it up top with the fans off-centre: For the components that are in there, a single 64mm radiator should be more than enough. So if I just go with the single: I’ll have much more ‘canvas’ and it should look a lot cleaner and less busy. At least that’s what I’m thinking; and my girls like it better this way, so I’ve got to listen to them! Whilst I did like the actual runs from the first iteration, this should work. Now we have a bit more space for whatever the #### we (I say we, my step-daughter is in charge of artwork) end up putting there.

The eagerly anticipated second delivery came in this week! A few fittings unfortunately came in chrome rather than black, which I imagine is due to issues with stock; which is completely understandable given current events. The extra-thick radiator did however really catch me by surprise. My intent was to install a 2nd Pacific C360 radiator at the front, for a total of 2 radiators (top and front). After a good couple of days trying different layouts, it became clear that I would have to have the slim rad up top and the thick rad at the front. Not only is the Pacific CL360 thicker, it is also a fair bit wider as I soon found out: Whilst it has all the mounting holes in the 120mm position, the actual dimensions of the radiator are that of the 140mm position. The knock-on effect is that I have to trim the notches for the acrylic a bit more, which isn't too bad; but it also resulted in having to experiment with the positioning of the Pacific DP100-D5 distribution plate. I also got my pipe-cleaners out to try and get an idea of possible tubing runs: Wasn't too keen on this first iteration, so pondered over it for a little while and tried again: As you can see, the 64mm thick radiator brings some issues. The View 51 only officially supports such a thick rad in the area that the distro plate currently sits. It kind of fits up top, but requires to be offset a fair bit; resulting in the fans being off center. So the front will have to do. It also unfortunately intrudes on quite a bit of space where artwork was orginally going to be, so will have to go back to the drawing board a little bit there as well. Once I trim and install the acrylic we will be able to get a better idea of how to proceed. As you can see, the distro plate also has to end up sitting quite low in order for drain port clearance. This also means that only 2 fans will be able to fit down below. Right, so before diving into more fabrication and prepping for paint etc., I wanted to make sure the components were working and that the radiators didn't have any leaks. I'd much rather take the time now to check, than find out AFTER all the work has been done. The run from the top radiator to the CPU block will definitely have to be remade, I was off by fair bit and really had to force placement. Fairly happy with the GPU>radiator run though. The CPU>front rad run is alright, but I will likely bend a fresh one later on. Originally it was going to enter the other port on the radiator, but the run from port back to the distro plate was just way too sharp; so had to change it up at the last minute. Whilst I do love the look of perfectly perpindicular bends, I also really like curvy ones like this little rascal. This one will definitely be a keeper. I also like the angle at which the previous bend had to it. The final run (first run in the loop order) sucks. Due to the position that I have to have the distro plate in, that port on the distro plate is too low. This bend will definitely be getting changed, I will most likely run from the higher port and come down at an angle like the CPU>fat rad run. But it will do for now for the sake of making sure everything works. Sure enough, that dodgy run had a slighly leak. The tubing was basically sliding out due to the tension on it, at least it will hold for this test. Thankfully that was the only issue. The D5 pump runs like a champ, and the radiators are rock solid with no leaks. The loop ended up taking 1.5L of fluid to fill, and getting all the air out was quite the headache; but I got there in the end. Mission accomplished, everything works and I have a better idea now of how the runs will likely look (they will be tweaked a fair bit by the end). Now time to drain the loop and dismantle everything. Having spent all of yesterday mucking around with the case, I am going to have to take a day or two of rest; my sciatica is unfortunately screaming at me. Next on the agenda is to modify/trim the acrylic sheet that was hugging the motherboard, now that the distro plate and thick radiator are there. Then I can move on to the remaining acrylic pieces that will inhabit the interior as well as around the fans. Once all of those have been done I can then move on to a full tear down of the case, a little bit of cutting, and then prep for paint. I also need to begin work on the back/side panel as well. Hopefully the weather this weekend cooperates with me! Thanks for stopping by folks, take care and stay safe!

Ahoy hoy mod fans! While I was waiting for the rest of the parts to turn up before I could do anything further on the case, I set my sights on some of the internals that could do with some tweaking. I needed to brighten the motherboard up as the main chamber of the case will have a bare metal finish and it would look like a black hole in amongst all the bright shiny metal. I've also never been much of a fan of modern motherboard heatsinks. I loved the fin-stacked heat-piped up solutions of yore and I'd even kept the one's off the Striker II NSE/Extreme boards for the ages after I'd binned the boards, but lost them in a move. 😔 What I did have was some Thermalright MOFSET heatsinks and a beefy Supermicro 1U copper cpu heatsink that I could use instead of or in combination with the existing ones Time to get this board stripped down. The CPU heatsink's mounting holes lined up perfectly with the mounting holes for the cover, almost like it was made to live there. Not sure it's supposed to come out like that 😳 Was very lucky not to strip any pins out of the CPU. Can just imagine how well that conversation would have gone down with Thermaltake 😅 After that heart exploding moment I gave the CPU, block and board a bit of a cleansing. This was the kind of setup I was looking at doing. I plan on milling a flat channel into the boards original heatsinks and using thermal glue to attach the Thermalright MOFSET heatsinks to them, rather than on there own. MOFSET sizes have grown a bit since these were made! There may be a bit of a fitting issue for the one on the left side MOFSET bank as it clashes a little with the IO shield. I'd rather keep that intact if possible. Those original heatsinks would still be too dark as is though, so we'll have to do something about that gun metal grey anodising. First off taking the fan off the chipset cooler, stripping the thermal pads (after measuring the sizes for their replacement) and giving them a good clean with TIM cleaner to remove the grease from the thermal pads, before they go for a little dip..... ... in some of this horrid stuff. Also know as Sodium Hydroxide. I'd picked up these old sweet containers to bathe the parts in and then rinse. Sadly I didn't get to eat the contents first, but given my ever increasing waistline that's probably for the best. I'd given them a good clean several times over and then a thorough rinse as I didn't want any contaminants in there that may react with the Sodium Hydroxide. You'll have to forgive me for the lack of pictures of the process, I was dolled up to the 9's in PPE (including a waterproof coat with a bin bag over it, was quite a sight) and didn't fancy getting my phone out whilst in the middle of it all. I placed the 3 tubs in the bath, seemed like a good place to do it as there's good ventilation in the bathroom and if things go south it can turn the taps on and ditch it down the drain quick. With the drain on my left, I used the left most container to have the solution in. I filled the other 2 with water as a 2 stage rinsing set up. I put 1 litre of water into the other and added 50g of sodium hydroxide crystals in gradually, in about 5 or 6 stages, mixing thoroughly with a toothbrush I had to scrub the pieces as the anodising came off. I used cold water to control/slow the reaction a bit so I could leave the pieces in long enough to get all the anodising off, without it just eating the aluminium away I put the large MOFSET cooler in first as I figured it could probably do with going in when it was fresh. It took a little while to get going and do anything, but sure enough bubbles started to come. I turned it over a few times, giving a little whirl in the fluid and you could see the colour fall off it. I then started giving it a helping hand with the toothbrush, especially in the little gaps. When the anodising had all come off I pulled it out and gave it a gentle shake, dropped it into the next tub with the clean water in, gave it a good whirl in there and and gentle clean with a second tooth brush, then into the third container for more fresh water, before finally putting it on some kitchen towels I'd set to the side to dry off. I then repeated the process with the rest of the pieces. The end result was better than I ever could have imagined 😍 The Aluminium on the newly stripped heatsinks is so bright, almost white. Look how it contrasts here to a piece of Aluminium sheet that I've had for a few years. And they look so good on the motherboard too! Super chuffed with the result. At least 3 chufty badges! Sadly the copper cpu block isn't going to fit, although given it's gargantuan size it shouldn't be all that surprising. I could have had a go at cutting off a corner here and there to get it to fit, but I don't think I've got the tools for the job and I'd probably end up ruining it. In all honesty with the amount of silver that's going to be around, the copper would probably look out of place anyway. Best to keep that for another day. I had a little test fit with the MOFSET heatsinks, either just sat on or with the help of an old thermal pad. Still not convinced that one on the left if going to fit without interfering with the IO shield. Thought I could maybe switch that one to the lower M.2 slot cooler. 🤔 In all honesty I'm not entirely convinced. Now I've got the stock heatsinks stripped, they look pretty dam cool. I have to be 100% sure as if I commit to it and it doesn't look good with the heatsinks on, I'll have wrecked the originals, so there's no going back. That can go on the back burner for now. There's a lot to be done still and I can always come beck to it later. It does look pretty dam sweet as is though. We got some new parts! 👏 Huge thanks to the guys at Scan (and DPD) for getting these over to us.🙌 Lots of fittings and adapters, a couple of litres of coolant, some 1m tubes for longer runs and backup for the inevitable mistakes, a nice thick rad and 9 of Thermaltake's new Riing Quad fans which I'm looking forward to getting snazzy with the NeonMaker software. I am NOT looking forward to the cable/sleeving job of 9 RGB fans 😭 Now putting heatsinks to one side, I'm still not done with the motherboard and whilst I have done some more stuff, it's not finished and I don't want to put it out half baked. I had hoped to finish it today but after 3 days of working on it on and off, this morning my body said no. 🤕 This seemed like a good place as any for a little update though, I hope you all enjoyed the show. For now I'll leave you with one last shot of those heatsinks in all their glittery glory. Hopefully I'll have another update for you later this week, so stay tuned crap fans! Same Crap Time, same Crap channel.

Update 2: 07/05/2020 Due to the corona virus it has limited on the amount of modding I can do. Due to having limited space in my house, I have no where to perform the modifications. This was originally going to be done at a friends house who has a workshop, Originally I didn't think the lockdown would last this long so I waited, however it looks like I am going to have to find the space.. I didn't want to leave you guys with nothing so here is what I have done so far. 1. I decided to build the parts in the case to see what the case is like etc. (without the watercooling). see image below. 2. Of course to get more performance out of the RX 5700 I flashed it with an RX 5700 XT Bios. This worked successfully and you get about a 7-10% fps increase. If you guys would like to see benchmarks of the difference I will be happy to make a video! 3. After waiting, I have recieved a bunch of parts needed for the modifications, I just need to start the updating, Notes: It will include, sandpaper, paint, saw, 3D printer, Laser Cutter, and dog tags

Thought I'd just do a quick update of some progress, so far have dismantled the case and started painting. The first is just a quick comparison of the silver with the recently released Xbox Controller, pretty pleased with the result, the back of the HDD cage has had a section cut out which is going to be used for power input for lighting / a raspberry pi: The raspberry pi mounted to one of the HDD slots (this is going to be used to feed a display showing PC stats): And various other pictures of progress, going to aim to finish all the smaller parts this week, then move onto painting the larger frame and panels next week:

Hi all back with my weekly update and over the last week iv started to fit the waterloop. I started with the gpu waterblock which I always get nervous doing. When I figured out what way the pipes would run I started bending.when I got all the pipes in i filled with distilled water to test for leakes and clean the system out. Now I've got to adjust the pipe and change the coolant to white. Its getting close now not much left to do so hopefully next week my build will be done.😁
