Show us your chassis!

Tt Andy

Recommended Posts

Better join in since I just finished most the little things finally in my build.

This is my Thermaltake P5 Aorus build

Specs : Hardware -

i7-8700k - OC to 4.8

Aorus ATC700 cpu cooler

Aorus Ultra gaming 2.0 motherboard

Nvidia RTX 2080

32g 3200mhz G.skill Trident ram

Thermaltake 850w Gold power supply

Samsung 256 960 evo (OS drive)

Intel optane 32g matched to 8TB Seagate archive drive

128 Toshiba SSD

1TB Blue and 250g Green western digital M.2 SSD fitted to NGFF boards

Custom lighting - Over 350 LED's, Lian li Strimer 24 and 8 pin, optic fiber lighting (lighting around motherboard and NFCC boards), custom infinity mirror power cable cover, and Thermaltake 3D printer fan bracket for rear top fan, Goverlay info screen, built bottom cover, Aorus SSD cover and Custom SSD cover made by JMMods (if you need custom backplates, covers and other things google the name and check out his website and youtube, inspired me to build my cable cover, does good work).

sorry if the photos are not that great :) Thanks for having a look.WP_20181031_18_36_51_Pro.thumb.jpg.b8c237feb33c2e58c36a74aa64d5f5fa.jpgWP_20181103_18_55_14_Pro.thumb.jpg.f10bb5025786ad4b1584229b086191dc.jpg





Link to comment
Share on other sites

  • 4 weeks later...

Hi Everyone,

           Here is my core P5 Build: All I use is a 90 mandrel, heat gun, clamp PVC cutter, ID/OD reamer and my eye. I am an electrician by trade :) Future plans: I just got a vinyl cutter and will be making a nuclear bio-hazard theme.


Core P5 Case (Green)

Tempered Glass Upgrade Kit

i7-8700K overclocked to 5 Ghz. V-core set to 1.32v

Aorus Z390 Master

Aorus 1080ti waterforce extreme (removed half of the metal overlay fir better visual of UV coolant.

Trident Z Ram 32GB

Changed power supply from Corsair in last pic to EVGA G3 Gold 1000w

Thermaltake PR22 D5 Pump/Resi combo.

EKWB CPU Block (Supreme EVO)

EKWB Coolstream Radiator 480mm

EKWB Fittings (compression)

EKWB 1000mm tube

Mayhem UV green coolant

NZXT Hue+ (1 controller) & 8 fans (I had these kicking around and used them instead of fans that can be sync'd with RGB fusion)

Darkside UV leds + extension. (7 total strips)

7 Port sata power header for UV lights to plug in to

Corsair M.2 x2


Thank you for looking!








Link to comment
Share on other sites

  • 1 month later...
  • 8 months later...
  • 2 months later...
12 minutes ago, Сана Лекомцев said:

I'm sitting on such a system

1)motherboard ASUS PRIME X570-P
2)   CPU  Ryzen 3700x
3)SSD CRUCIAL bx500 240GIGS . HARD DISKS 1  Terabyte Western Digital Blueи 500 GIGS Western Digital GREEN
4)  graphics card    Asus AMD Radeon RX 580 Strix OC (8 GIG 256 бит)
5)  cooling system  depcool  lucifer V2  with additional cooler      GELID.
6)  POWER SUPPLY  Enermax     revolution  XT2 750 Wатт (  according to the documents   744Wатт)
7)  POWER SUPPLY     CHECKED ME FOR WRITTEN  332 wаtt (  he stupidly air - blows out of the body   )
😎   body          Thermaltake Core X71 Tempered Glass
9)  RAM crashed ballistic 16 гигов   on   clean  3200 DDR4 micron
10)   LED Strip Light Apeyron 00-17








Link to comment
Share on other sites

  • 1 month later...

This is my build Level 20 XT build with a custom 17" waterfall reservoir, the case is holographic wrap and made a new motherboard shelf

  • 1 x Thermaltake Level 20 XT chassis
  • 1 x Thermaltake M360 Plus water-cooling kit
  • 1 x Thermaltake 850W Toughpower ‘SYNC’ Edition PSU
  • 1 x Asus Socket AM4 X470-F gaming
  • 1 x Asus Duel RTX 2080
  • 1 x AMD Ryzen 7 2700X CPU
  • 1 x Adata SX6000 256GB M.2 SSD
  • 1 x Thermaltake Toughram 3200Hz 16GB (2 x 8GB) DDR4









53nytNYl.jpg 3EHVOYil.jpg


Link to comment
Share on other sites

  • 3 weeks later...

So this is my gamer chick mod(Me=Chick)😂. First time modding/building a system I was relieved at how easy it was to play with this case. Case is the Thermaltake Core V1. I loved the modular style of this chassis, so many different orientation possibilities. All parts for this build where purchased from Amazon. I painted the exterior with a rose gold metallic paint and champagne pink in the interior. I also created a new filigree front panel. Added some argb fans (One 120mm at the front and one on the top panel. I have the Thermaltake rgb 500W power supply venting out the right side of the case. Motherboard is the Asus ROG Strix B450i-Gaming. CPU is AMD Ryzen 5 3400G . I have a 256gb nvme.2 SSD installed on the mobo. Memory is being changed out to 16 Gb 3200mhz rgb G Skill Tridentz. And I am planning on watercooling this as well in the next few weeks hence the open space in the front. All in all I would definitely use this case again for a build and highly recommend.






Link to comment
Share on other sites

  • 2 months later...

I got the VT-20 micro ATX case with this inside:

msi geforce rtx 2080 super gaming x trio

8GB x 4 thermaltake one ddr4 pc3200 RAM

5 140mm thermaltake ring quad fans

280mm floe ring AIO cooler (replaced it's radiator fans with the quads)

msi z390m gaming edge ac m-ATX motherboard

2 samsung 500gb 970 evo plus m.2 nvme drives striped together for my system drive

3 500GB teamforce delta max rgb ssds striped togethet for a 1.5TB data drive

intel i9-9900k proc


there's over 500 individually addressable LEDs in this sucker and with my Razer gear and Synapse, I can sync all of them together. mix in some Phillips Hue color lights and you have yourself one helluva light show.











Link to comment
Share on other sites

  • 5 months later...

IMG_20190824_205004.thumb.jpg.c4331665a6b064c03f06401055ce4c53.jpgIMG_20191029_213656.thumb.jpg.467376128b2d7d1b33d4bbf68d58d49f.jpgIMG_20200427_074209.thumb.jpg.6420bab549f9ceaea3e43f348764b9ca.jpgIMG_20200427_074218.thumb.jpg.48e94f9b53e24c16854f5acb64f27a2e.jpgIMG_20200427_123820.thumb.jpg.85c1531f7943055d14aeb797c223105a.jpgIMG_20200427_125848.thumb.jpg.e53f0bb736a55d4d2ec38f4ed60ae424.jpgHello my name is Reinaldo and I am setting up my PC, where I post the steps on the RC WORK channel and today I am going to share some of the photos with you and still continue this project.

Chassis: View 71 TG RGB
ToughoPower Gran RGB 850W power supply
Riing Trio 140mm RGB Fans
Riing Plus 140mm RGB Fans
Asrock Z390 Phantom Gaming 7 motherboard
Intel i5 9400K processor
Ram T-Force Dark-Z 2x16 (32GB) 3600Mhrz - TeamGroup
Video Card GTX 1060 6GB - Gigabyte
X1 RGB Keyboard
Mouse Ventus Z
Draconem Rgb Mousepad
Headset Chromos

Note: Current configuration, pictures may appear with previous configuration

Chassis: View 71 TG RGB
ToughoPower Gran RGB 850W power supply
Riing Trio 140mm RGB Fans
Riing Plus 140mm RGB Fans
Rampage IV Extreme motherboard
Intel i7 3930K processor
Dominator 4x4 ram (16GB) - Cosair
Video Card GTX 1060 6GB - Gigabyte
X1 RGB Keyboard
Mouse Ventus Z
Draconem Rgb Mousepad
Headset Chromos















Link to comment
